Diesel Engine Driven Multistage Emergency Drainage Pumps 55-100m3/H DN100

Product Categories
CHANGSHA SANCHANG PUMP CO., LTD.
Contact Now

Diesel Engine Driven Multistage Emergency Drainage Pumps 55-100m3/H DN100

  • 1
  • 2
  • 3

Brand Name : SANCHANG

Model Number : D85-45X5

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1 pcs

Price : Negotiated

Payment Terms : L/C, T/T

Supply Ability : 300pcs/month

Delivery Time : 30 working days

Packaging Details : Plywood Case

Flow Capacity : 55-100m3/h

Delivery Head : 78-459m

Inlet/Outlet Dia. : 100mm/100mm

Working Pressure : <6.88MPa

Liquid Temperature : 0-80 ℃

Application : Clean Water, Sewage, Hot Water, Corrosive Liquid, Mining Water

Material : Cast Iron, Cast Steel, S.S304, S.S316, Duplex S.S2205

Dirven By : Electric Motor / Diesel Engine

Voltage : 380V/415V/440V/460V/3000V/6000V

Speed : 2980/3560rpm

Seal : Gland Packing/Mechanical Seal

Frequency : 50/60Hz

Contact Now

Diesel Engine Driven Multistage Emergency Drainage Pumps D85-45X5

Description

Emergency Drainage Pump is a sort of product used under specific site conditions, especially sites lack of electric power supply.It is an effective supplement to the existing pumping station while insufficient working capacity. It is usually used to handling water flooding, it could help and restore communities around the world from the damaging effects of floods caused by storm. And it is also widely applied into water intaking projects temporaryly, especialy in outdoor fire control and drought resistant projects.

Sanchang designs and manufactures a full range of portable emergency drainage pumps specifically built to help combat unwanted water from floods as well as wild sites water intaking.

Parameters of Multistage Emergency Drainage Pump D85-45X2-9

Flow Capacity 55-100 m3/h Delivery Head 78-459 m
Inlet/Outlet Dia. DN100/DN100 mm Working Pressure ≤ 6.88 MPa
Liquid Temperature 0 - 80 ℃ Driven By Electric Motor / Diesel Engine
Seal Type Mechanical seal / Gland packing Liquid Clean water or similar
Material of Construction Cast Iron / Cast Steel / S.S304 / S.S316 / Duplex S.S2205

Diesel Engine Driven Multistage Emergency Drainage Pumps 55-100m3/H DN100

Main Parts Configuration
The pump could be applied to transfer different kinds of liquid by customized wet parts, here followed our recommendation of main configuration:
Parts Name Fresh Water Sewage Raw Water Corrosive Raw Water Oil Water Liquid
Pump Body Cast Iron Ductile Iron Cast Steel S.S304/S.S316/S.S2205 S.S304/S.S316
Shaft Cast Iron S.S420 40Cr/42CrMo S.S630/S.S2205 S.S420/40Cr
Shaft Sleeve Carbon Steel S.S420 S.S420 S.S316/S.S630/S.S2205 S.S304/S.S316
Impeller Cast Iron Ductile Iron Cast Steel S.S304/S.S316/S.S2205 S.S304/S.S316
Wearing Ring Cast Iron Ductile Iron Cast Steel S.S304/S.S316/S.S2205 S.S304/S.S316
Bearing China Make/NSK/SKF/Customized
Seals Mechanical Seals/Gland Packing Seals

Diesel Engine Driven Multistage Emergency Drainage Pumps 55-100m3/H DN100

Diesel Engine Driven Multistage Emergency Drainage Pumps 55-100m3/H DN100
